SuperTrak PHARMA8™
SuperTrak PHARMA8™ is a linear motion solution designed for aseptic processes such as the manufacturing or packing of sterile products.
To protect the product from contamination, the Supertrak PHARMA8™ conveyance platform provides minimal disruption of downward air flow and minimal disturbance of unidirectional laminar airflow within an isolator.
Increased speeds, lowered settling times, and rapid acceleration improve cycle times and overall productivity. Products get in and out of stations as quickly as possible spending more time in process and less time in motion.
Increased precision means that stopper cylinders, locate tooling, and other add-ons may not be required; this results in decreased cycle times with fewer parts and less engineering. Ultimately your automation is more productive and requires less space on the factory floor.
Independently specify each shuttle’s velocity and acceleration, position, and destination, allowing for easier control of asynchronous motion.
Maximum Speed
2.5 m/s
Acceleration
Up to 30m/s²
Stop Repeatability
± 0.01 mm straight section
± 0.025 mm turn section
Shuttle Payload
8.5 kg maximum
Process on Curve
Full control
Shuttle Options
Standard shuttle configuration with 2 or 3-magnet array
Lubricants
No wet lubricant required
Loop Size
1m and 2m plus turns in single piece
3m plus turns and more in module build up
Surface and Roughness
Stainless Steel 316L, Ra < 0.8μm on visible area surfaces
Design Ratings
Design conforms to EEC-cGMP, ISO 9001 & ISO 13485
Particulate Levels Rating
Suitable for ISO 5, ISO 14644.1 & EU GMP Annex 1 Grade A
Washing and
Decontamination
Vaporized hydrogen peroxide (VHP), quats, ethanol, IPA and
traditional sporicidals.
Wash In Place (WIP) with spray gun and spray ball
Communication
Have questions or need assistance?
Whether you’re looking for information on our services, want to schedule a personalized review of your application with a dedicated member of our applications team, or need help with anything else – we’re here for you!
Contact us now and let us know how we can assist you. Your inquiries are important to us, and we’re committed to providing the support you need.
How can we help you today?
Learn how one company reduced floor space and overall system cost by switching from traditional conveyance to Smart Conveyance.
Automation can be complex. Smart Conveyance doesn’t have to be. Download the Engineers Guide to see how Smart Conveyance can bring significant benefits to automation design and performance.
The individualized control of each shuttle or part carrier on the platform offer complete flexibility while simplifying the manufacturing process.
The SuperTrak GEN3™ platform provides machine builders with a number of features to enable high performance automation with less risk.
Powered by linear servo motor technology, SuperTrak GEN3™ allows independent shuttle control with fast and precise motion, providing automation designers with an incredible amount of flexibility to increase productivity and minimize space.
1000mm
500mm Diameter
800mm Diameter
600mm Radius
152 up to 600mm
4 m/s
1G with 10 kg payload*
4G with 1 kg payload*
10+ kg per shuttle
Full control
Standard shuttle configuration with 2 or 3 magnet array options
Maximizing the functionality of your factory automation in the minimum amount of space is essential for today’s manufacturers and their industrial automation processes. The different configurations provide the flexibility for tooling to be mounted on the inside, outside, overtop, or underneath.
The new 90° configuration offers the same floor saving space as a servo or indexing dial. The 90° curved sections allow for even more configuration options such as a squared circle or rectangle. When using this configuration, the system can grow in both length and width. Two 90° sections back to back allow for a system that is 1200mm wide. Manufacturers can fit even more tooling on the inside to minimize system footprint.
Additional space on the inside of the conveyance platform allows manufacturers many options to mount tooling on the inside. This helps minimize the amount of space your factory automation requires on the factory floor.
Offers manufacturers options to mount tooling on the outside of the conveyance platform.
Being able to easily scale your business is essential for the success of today’s manufacturers. The flexible nature of the SuperTrak CONVEYANCE™ platform allows manufacturers to expand your systems by easily adding additional modular sections as your business grows and as products change. Easily reconfigure the functionality of the conveyance platform as business requirements change.
Your team of engineers and designers can quickly scale system programming for additional stations and processes utilizing target routing within our TrakMaster™ software. All of this high-performance capability is achieved with less effort because of the amount of integrated functionality that’s packed into the platform. Scalability is essential for the success of your business.
Best suited for applications where Smart Conveyance is an effective solution.
With a 10+kg weight capacity for each shuttle, the platform’s independent shuttle control, speed, and precision delivers high performance capability with less engineering by utilizing the amount of integrated functionality packed in the platform.
Popular across industries including, medical device manufacturing, pharmaceutical, automotive and consumer products.
Best suited for manufacturing processes with a one-directional part flow. The over/under configuration has a slightly lower weight capacity of 4kg per shuttle on curves but maintains the 10kg capacity on straights. Utilized in applications where floor space is at a premium, the over/under configuration has seen much success in automotive battery assembly and packaging applications.
